80ED
Category： Askar
The Askar 80ED is a telescope with an aperture of 80mm, a focal length of 560mm, and a focal ratio of F7. The optical lens features a two-element structure, consisting of one ED glass and one standard achromatic glass.
Retail Price:
$ 399
20
In stock Back OrderedUpon package arrival, expect to pay customs duties and VAT to customs
隐藏域元素占位
这里是标题一h1占位文字
Category： 这里是占位文字
这里是占位文字
-
尺码
- S
- M
- XL
- XXL
-
颜色较长
-
红
-
粉
-
蓝蓝蓝蓝蓝
-
黑色黑色黑色黑色
-
Retail Price:
¥ 55542
库存剩余
465465123
Upon package arrival, expect to pay customs duties and VAT to customs.
- Product introduction
- Product introduction
- Specifications
- Video
- Images
- Download
-
- Commodity name: 80ED
- Commodity ID: 80ED
The Askar 80ED is a telescope with an aperture of 80mm, a focal length of 560mm, and a focal ratio of F7. The optical lens features a two-element structure, consisting of one ED glass and one standard achromatic glass.
-
-
Parameters
Aperture size
80mm
Focal length
560mm
Focal ratio
f/7
Objective lens
Doublet (including one ED glass)
Total length
404mm(when the dew shield is contracted)
505mm(when the dew shield is stretched)OTA weight
1.7kg
Gross weight（including tube ring and dovetail plate）
2kg
Rear-end thread type
2" adapter
Standard package items
a manual
Product Size Diagram
The Locking Screw Position Diagram
Electronic Focuser Assembly Diagram
Optical Path Diagram
Spot Diagram
Longitudinal Aberration
-
NGC6960 | 张宇航 | ASKAR 80ED + 1.0x Flattener + ZWO ASI2600MC
NGC 6960 | 阿强 | ASKAR 80ED + 1.0x Flattener + QHY268C
M8 | 小豆枕 | ASKAR 80ED + 1.0x Flattener + ZWO ASI2600 MCpro
NGC 6888 | Hang | ASKAR 80ED + 0.7x Reducer + ZWO ASI 2600MM Pro
M16 | Cayetana Saiz | ASKAR 80ED + 0.7x Reducer + ZWO ASI 2600MC Pro
NGC 7000 | Hang | ASKAR 80ED + 0.7x Reducer + ZWO ASI 2600MM Pro
Product introduction
Specifications
Parameters | |
Aperture size | 80mm |
Focal length | 560mm |
Focal ratio | f/7 |
Objective lens | Doublet (including one ED glass) |
Total length | 404mm(when the dew shield is contracted) |
OTA weight | 1.7kg |
Gross weight（including tube ring and dovetail plate） | 2kg |
Rear-end thread type | 2" adapter |
Standard package items | a manual |
Product Size Diagram |
The Locking Screw Position Diagram |
Electronic Focuser Assembly Diagram |
Optical Path Diagram |
Spot Diagram |
Longitudinal Aberration |
Video
Images
Download
