Z4

According to the users’ and market demands, Sharpstar has newly launched an integrated astrograph—Z4. It has an aperture of 100mm and the focal ratio is f/5.5. Z4 is a sextuplet astrograph with three pieces of lens at the front and three pieces at the back, and two of them are ED glasses. Just like other series of Sharpstar astrographs, Z4 is designed as self-flattened so there is no need to calculate the back focus. You can just make the target stay at the focus, and the optical system is perfect for imaging.

leave a message now >

Product introduction

100mm aperture

550mm focal length

Sextuplet air- spaced APO design

APS frame

Central RMS radius 3um

No need for flattener

No need to calculate the backfocus

Various adapter

Retractable lens hood

300mm dovetail plate

multi-functional handle

3.4" large rack- pinion focuser

1:10 fine adjustment




According to the users’ and market demands, Sharpstar has newly launched an integrated astrograph—Z4. It has an aperture of 100mm and the focal ratio is f/5.5. Z4 is a sextuplet astrograph with three pieces of lens at the front and three pieces at the back, and two of them are ED glasses. Just like other series of Sharpstar astrographs, Z4 is designed as self-flattened so there is no need to calculate the back focus. You can just make the target stay at the focus, and the optical system is perfect for imaging.



The appearance of Z4 breaks through the previous style of Sharpstar with its matte gray coating. Light gray lens tube plus dark gray focuser and tube ring, make the astrograph looks calm but vibrant. The tube ring has a handle on the top which is easy to carry and assemble. The handle is designed as a slot on which you can mount a finder base, etc.



Z4 uses a large 3.4” focuser with a 1:10 fine adjustment knob and a 360° rotator for easy focusing and angle adjustment. It has M86, M68, M54, M48 adapters, and the M48 one has an internal thread that can fit 2” filters. And a 300mm Vixen-style dovetail plate, makes it easier to balance on the equatorial mount.

Specifications

Z4

Focal ratio

f/5.5

Objective lens

sextuplet fully air-spaced APO (including two ED glasses)

Image circle

36mm

Total length

482mm

Net weight

4.3kg

Gross weight

5.6kg(without the aluminum box)

Rear-end thread

M48×0.75 male thread

Tapered adapter

      M86×1-M68×1
          M68×1-M54×0.75
          M54×0.75-M54×0.75
          M54×0.75-M48×0.75(with M48×0.75 filter thread)

Standard package items

a tube ring, a dovetail plate, a handle, a 4-piece photographical adapter, a warranty,a manual





Video

Images

photo by SANDWALL

NGC 6960 the Western Veil Nebul  | Sharpstar Z4   100mm f5.5 Astrograph  | Askar Coulor Magic 3nm Duo Narrow Band Filter

IC1805 Heart Nebula  |  Sharpstar Z4+ZWO 2600MM
